Simple Arc Punching Machine For Scaffolding

Simple Arc Punching Machine For Scaffolding

System Pressure:          5Mpa
Tons:                     2.5 T
Motor power:               3Kw
Cylinder stroke :              70mm
Max Material thickness :       3mm,(Thickness enlarge as per requirement)
Punching Rate:              30-60times/min
Voltage:                  440V
Antiwear hydraulic oil:      Summer(46#)Winter(32#)
Dimensions :               800x1200x550 mm
Net Weight :                200KGS


DETAILED
This is a Simple work station Arc Punching machine for the aluminium scaffoldings.
It’s easy to operate the machine,
And the machine can be chosen to be punching holes or punching arc . easy to switch the mode.


Work Station:             Single Work Station
Control :        Manual feeding punching by hydraulic power
System Pressure:          5Mpa
Tons:                     2.5 T
Motor power:               3Kw
Cylinder stroke :              70mm
Max Material thickness :       3mm,(Thickness enlarge as per requirement)
Punching Rate:              30-60times/min
Voltage:                  440V
Antiwear hydraulic oil:      Summer(46#)Winter(32#)
Dimensions :               800x1200x550 mm
Net Weight :                200KGS
